View tip120-127 datasheet:

Continental Device India LimitedAn ISO/TS 16949, ISO 9001 and ISO 14001 Certified CompanyPLASTIC POWER TRANSISTORS TIP120 TIP125TIP121 TIP126TIP122 TIP127NPN PNPTO-220Plastic PackageHigh Power Switching, Hammer Drive, Pulse Motor Drive and Inductive Load Drive ApplicationsABSOLUTE MAXIMUM RATINGS DESCRIPTION TIP120/125 TIP121/126 TIP122/127 UNITVCEO Collector Emitter Voltage 60 80 100 VCollector Base Voltage VCBO 60 80 100 VEmitter Base Voltage VEBO 5 VICCollector Current Continuous 5 ACollector Current Peak ICM 8 ABase Current IB 120 mAPower Dissipation upto Tc=25C PD 65 WDerate above 25C 0.52 W/CPower Dissipation upto Ta=25C PD 2 WDerate above 25C 16 mW/CUnclamped Inductive Load *E 50 mJEnergy Operating And Storage Junction Tj, Tstg- 65 to +150 CTemperature* IC=1A, L=100mH, P.R.F.=10Hz, Vcc=20V, RBE=100 THER
