View tip120 tip121 tip122 tip125 tip126 tip127 datasheet:

TIP120/121/122TIP125/126/127COMPLEMENTARY SILICON POWER DARLINGTON TRANSISTORS STMicroelectronics PREFERREDSALESTYPESDESCRIPTION The TIP120, TIP121 and TIP122 are siliconEpitaxial-Base NPN power transistors inmonolithic Darlington configuration mounted inJedec TO-220 plastic package. They are intentedfor use in power linear and switching applications.32The complementary PNP types are TIP125,1TIP126 and TIP127, respectively.TO-220INTERNAL SCHEMATIC DIAGRAMR Typ. = 5 K R Typ. = 150 1 2ABSOLUTE MAXIMUM RATINGSSymbol Parameter Value UnitNPN TIP120 TIP121 TIP122PNP TIP125 TIP126 TIP127VCBO Collector-Base Voltage (IE = 0) 60 80 100 VVCEO Collector-Emitter Voltage (IB = 0) 60 80 100 VVEBO Emitter-Base Voltage (IC = 0) 5 VI Collector Current 5 ACI Collector Peak Current 8 ACMI Base Current 0.1 ABPtot Total Dissipation a
