TIP122FPTIP127FPCOMPLEMENTARY SILICON POWER DARLINGTON TRANSISTORS STMicroelectronics PREFERREDSALESTYPES FULLY INSULATED PACKAGE (U.L.COMPLIANT) FOR EASY MOUNTINGDESCRIPTION The TIP122FP is a silicon Epitaxial-Base NPNpower transistor in monolithic Darlingtonconfiguration mounted in Jedec TO-220FP fully32molded isolated package. It is intented for use in1power linear and switching applications.The complementary PNP type is TIP127FP.TO-220FPINTERNAL SCHEMATIC DIAGRAMR Typ. = 5 K R Typ. = 150 1 2ABSOLUTE MAXIMUM RATINGSSymbol Parameter Value UnitNPN TIP122FPPNP TIP127FPV Collector-Base Voltage (I = 0) 100 VCBO EVCEO Collector-Emitter Voltage (IB = 0) 100 VVEBO Emitter-Base Voltage (IC = 0) 5 VI Collector Current 5 ACICM Collector Peak Current (tp
