View tip122l datasheet:

TIP122L(BR3DA122LQ) Rev.C Feb.-2015 DATA SHEET / Descriptions TO-126 NPN Silicon NPN transistor in a TO-126 Plastic Package. / Features TIP127L(BR3CA127LQ) Complement to TIP127L(BR3CA127LQ). / Applications Medium power linear switching applications. / Equivalent Circuit / Pinning 1 2 3 PIN1Emitter PIN 2Collector PIN 3Base / hFE Classifications & Marking See Marking Instructions.http://www.fsbrec.com 1 / 6 TIP122L(BR3DA122LQ) Rev.C Feb.-2015 DATA SHEET / Absolute Maximum Ratings(Ta=25) Parameter Symbol Rating Unit Collector to Base Voltage VCBO 100 VCollector to Emitter Voltage VCEO 100 VEmitter to Base Voltag
