View tip125 datasheet:

PNP EPITAXIALTIP125/126/127 DARLINGTON TRANSISTORMEDIUM POWER LINEARTO-220SWITCHING APPLICATIONS Complement to TIP120/121/122ABSOLUTE MAXIMUM RATINGSCharacteristic Symbol Rating Unit Collector-Base Voltage VCBO -60 V: TIP125 -80 V: TIP126 -120 V: TIP127 Collector Emitter Voltage: TIP125 VCEO -60 V: TIP126 -80 V: TIP127 -120 V1.Base 2.Collector 3.Emitter Emitter-Base Voltage VEBO -5 V Collector Current (DC) IC -5 A Collector Current (Pulse) IC -8 A Base Current (DC) IB -120 mA Collector Dissipation ( TA=5 ) PC 2 W Collector Dissipation ( TC=5 ) PC 65 W Junction Temperature TJ 150 Storage Temperature TSTG -65 ~ 150 ELECTRICAL CHARACTERISTICS (TC =25 )Characteristic Symbol Test Conditions Min Max Unit Collector Emitter Sustaining Voltage VCEO(sus) : TIP125 IC = -100mA, IB = 0 -60 V: TIP126 -80 V: TIP127 -120 V Collecto
