View tip127 datasheet:

UTC TIP127 PNP EPITAXIAL PLANAR TRANSISTORPNP EPITAXIAL TRANSISTORDESCRIPTIONThe UTC TIP127 is a PNP epitaxial transistor, designedfor use in general purpose amplifier low-speed switchingapplications.BCETO-220ABSOLUTE MAXIMUM RATINGS (Ta=25C)PARAMETER SYMBOL VALUE UNITStorage Temperature Ts -55 ~ +150 CJunction Temperature Tj 150 CTotal Power Dissipation PD 65 WCollector to Base Voltage VCBO 100 VCollector to Emitter Voltage VCEO 100 VEmitter to Base Voltage VEBO 5 VIC Collector Current 5 AELECTRICAL CHARACTERISTICS(Ta=25C)PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITCollector-Emitter Breakdown Voltage BVCEO IC=100mA 100 VCollector Cut-Off Current ICBO VCB=100V 200 uACollector-Cut-Off Current ICEO VCE=50V 500 uAEmitter Cut-Off Current IEBO VEB=5V 2 mACollector-Emitter Saturation Voltage VCE(SAT)1 IC=3A, IB=12mA 2 VColl
