View tip127f datasheet:

JIANGSU CHANGJING ELECTRONICS TECHNOLOGY CO., LTD TO-220F Plastic-Encapsulate Transistors TO-220F 1.BASETIP127F DARLINGTON TRANSISTOR (PNP)2.COLLECTOR3.EMITTERFEATURES 1 2 3CPNP BMedium Power Complementary Silicon Transistors R 1R 2E typ. =5 K typ. =210 R1 R2 TIP127F=Device code Solid dot=Green moldinn compound device, if none,the normal device TIP127FXXXX=CodeXXXXMAXIMUM RATINGS (Ta=25 unless otherwise noted) Symbol Parameter Value Unit VCBO Collector-Base Voltage -100 V-100VCEO Collector-Emitter Voltage VVEBO Emitter-Base Voltage -5 VIC Collector Current -Continuous -5 A PC Collector Power Dissipation 2 W RJA Thermal Resistance, Junction to Ambient 62.5 /W RJC Thermal Resistance, Junction to Case 1.92 /W TJ,Tstg Operation Junction and -55~+150 Storage Temperature Range www
