View tip31 tip31a tip31b tip31c datasheet:

tip31_tip31a_tip31b_tip31ctip31_tip31a_tip31b_tip31c

Inchange Semiconductor Product Specification Silicon NPN Power Transistors TIP31/31A/31B/31C DESCRIPTION With TO-220C package Complement to type TIP32/32A/32B/32C APPLICATIONS Medium power linear switching applications PINNING PIN DESCRIPTION1 Base Collector;connected to 2 mounting base 3 EmitterAbsolute maximum ratings(Ta=25) SYMBOL PARAMETER CONDITIONS VALUE UNITTIP31 40TIP31A 60VCBO Collector-base voltage Open emitter V TIP31B 80TIP31C 100 TIP31 40TIP31A 60VCEO Collector-emitter voltage Open base V TIP31B 80TIP31C 100 VEBO Emitter-base voltage Open collector 5 V IC Collector current (DC) 3 A ICM Collector current-Pulse 5 AIB Base current 1 ATC=25 40 PC Collector power dissipation w Ta=25 2 Tj Junction temperature 150 Tstg Storage temperature -65~150 INCHANGE SEMICONDUCT
