View tip35 tip35a tip35b tip35c datasheet:
Inchange Semiconductor Product Specification Silicon NPN Power Transistors TIP35/35A/35B/35C DESCRIPTION With TO-3PN package Complement to type TIP36/36A/36B/36C DC current gain hFE=25(Min)@IC=1.5A APPLICATIONS Designed for use in general purpose power amplifier and switching applications. PINNING PIN DESCRIPTION1 Base Collector;connected to 2 mounting base Fig.1 simplified outline (TO-3PN) and symbol 3 EmitterAbsolute maximum ratings(Ta=) SYMBOL PARAMETER CONDITIONS VALUE UNITTIP35 40TIP35A 60VCBO Collector-base voltage Open emitter V TIP35B 80TIP35C 100 TIP35 40TIP35A 60VCEO Collector-emitter voltage Open base V TIP35B 80TIP35C 100 VEBO Emitter-base voltage Open collector 5 V IC Collector current 25 A ICM Collector current-peak 40 A IB Base current 5 APC Collector power dissipation TC=25 125 WTj Juncti
