View tip35a tip35b tip35c tip36a tip36b tip36c datasheet:

tip35a_tip35b_tip35c_tip36a_tip36b_tip36ctip35a_tip35b_tip35c_tip36a_tip36b_tip36c

TIP35A, TIP35B, TIP35C(NPN); TIP36A, TIP36B,TIP36C (PNP)Complementary SiliconHigh-Power Transistorshttp://onsemi.comDesigned for general-purpose power amplifier and switchingapplications.25 AMPEREFeaturesCOMPLEMENTARY SILICON 25 A Collector Current POWER TRANSISTORS Low Leakage Current - 60-100 VOLTS, 125 WATTSICEO = 1.0 mA @ 30 and 60 V Excellent DC Gain - hFE = 40 Typ @ 15 A High Current Gain Bandwidth Product -hfe = 3.0 min @ IC = 1.0 A, f = 1.0 MHz These are Pb-Free Devices*SOT-93 (TO-218)MAXIMUM RATINGSCASE 340DSTYLE 1TIP35A TIP35B TIP35CTIP36A TIP36B TIP36CRating Symbol UnitCollector - Emitter Voltage VCEO 60 80 100 VdcCollector - Base Voltage VCB 60 80 100 VdcTO-247CASE 340LEmitter - Base Voltage VEB 5.0 VdcSTYLE 3Collector Current IC Adc25- Continuous40- Peak (Note 1)Base Current
