View tip41 tip41a tip41b tip41c datasheet:

TIP41/41A/41B/41CSilicon NPN Power TransistorsDESCRIPTIONDC Current Gain -h = 30(Min)@ I = -0.3AFE CCollector-Emitter Sustaining Voltage-: V = 40V(Min)- TIP41; 60V(Min)- TIP41ACEO(SUS)80V(Min)- TIP41B; 100V(Min)- TIP41CComplement to Type TIP42/42A/42B/42CAPPLICATIONSDesigned for use in general purpose amplifer andswitching applicationsABSOLUTE MAXIMUM RATINGS(T =25)aSYMBOL PARAMETER VALUE UNITTIP41 40TIP41A 60V Collector-Base Voltage VCBOTIP41B 80TIP41C 100TIP41 40TIP41A 60V Collector-Emitter Voltage VCEOTIP41B 80TIP41C 100V Emitter-Base Voltage 5 VEBOI Collector Current-Continuous 6 ACI Collector Current-Peak 10 ACMBase Current 2 AIBCollector Power Dissipation65T =25CP WCCollector Power Dissipation2T =25aT Junction Temperature 150 jStorage Temperature Range -65~150
