View tip41 tip41a tip41b tip41c tip42 tip42a tip42b tip42c datasheet:

TIP41, TIP41A, TIP41B,TIP41C (NPN); TIP42, TIP42A,TIP42B, TIP42C (PNP)Complementary SiliconPlastic Power Transistorshttp://onsemi.comDesigned for use in general purpose amplifier and switchingapplications.6 AMPEREFeaturesCOMPLEMENTARY SILICON ESD Ratings: Machine Model, C; > 400 VPOWER TRANSISTORSHuman Body Model, 3B; > 8000 V40-60-80-100 VOLTS, Epoxy Meets UL 94 V-0 @ 0.125 in65 WATTS Pb-Free Packages are Available*MAXIMUM RATINGSMARKINGDIAGRAMRating Symbol Value UnitCollector-Emitter Voltage TIP41, TIP42 VCEO 40 Vdc4TIP41A, TIP42A 60TIP41B, TIP42B 80TIP41C, TIP42C 100Collector-Base Voltage TIP41, TIP42 VCB 40 Vdc TO-220ABTIP4xxGTIP41A, TIP42A 60CASE 221AAYWWTIP41B, TIP42B 80STYLE 1TIP41C, TIP42C 100 123Emitter-Base Voltage VEB 5.0 VdcCollector Current- Continuous IC 6.0 AdcPeak 10TIP4xx = Device
