View tip41 tip41a tip41b tip41c to-220 datasheet:
MCCMicro Commercial ComponentsTMTIP41/41A/41B/41C20736 Marilla Street ChatsworthMicro Commercial ComponentsCA 91311Phone: (818) 701-4933Fax: (818) 701-4939Features Lead Free Finish/RoHS Compliant(Note 1) ("P" Suffix designates RoHS Compliant. See ordering information) Silicon NPN The complementary PNP types are the TIP42 respectively Epoxy meets UL 94 V-0 flammability rating Moisure Sensitivity Level 1Power Transistors Marking : Part NumberAbsolute Maximum Ratings @ Ta = 25 (unless otherwise noted) Symbol Parameter Value UnitTO-220VCBO 40 TIP41 B C Collector-base voltage 60 V TIP41A (Open emitter) 80 S F TIP41B 100 TIP41C VCEO Q 40 TIP41 T Collector-emitter voltage 60 V TIP41A (Open base) 80 TIP41B A 100 TIP41C U VEBO Emitter-base Voltage (Open collector) 5 V IC Collector
