View tip41are datasheet:
Order this documentMOTOROLAby TIP41A/DSEMICONDUCTOR TECHNICAL DATANPNTIP41AComplementary Silicon PlasticTIP41B*Power TransistorsTIP41C*. . . designed for use in general purpose amplifier and switching applications.PNP CollectorEmitter Saturation Voltage VCE(sat) = 1.5 Vdc (Max) @ IC = 6.0 AdcTIP42A CollectorEmitter Sustaining Voltage VCEO(sus) = 60 Vdc (Min) TIP41A, TIP42ATIP42B*VCEO(sus) = 80 Vdc (Min) TIP41B, TIP42BVCEO(sus) = 100 Vdc (Min) TIP41C, TIP42C High Current Gain Bandwidth ProductTIP42C*fT = 3.0 MHz (Min) @ IC = 500 mAdc*Motorola Preferred Device Compact TO220 AB Package6 AMPERE
