View tip41g tip41ag tip41bg tip41cg tip42g tip42ag tip42bg tip42cg datasheet:

TIP41G, TIP41AG, TIP41BG,TIP41CG (NPN),TIP42G, TIP42AG, TIP42BG,TIP42CG (PNP)Complementary Siliconwww.onsemi.comPlastic Power Transistors6 AMPEREDesigned for use in general purpose amplifier and switchingapplications.COMPLEMENTARY SILICONPOWER TRANSISTORSFeatures Epoxy Meets UL 94 V-0 @ 0.125 in 40-60-80-100 VOLTS, These Devices are Pb-Free and are RoHS Compliant*65 WATTSMAXIMUM RATINGSPNP NPNRating Symbol Value Unit COLLECTOR COLLECTOR2,4 2,4Collector-Emitter Voltage VCEO VdcTIP41G, TIP42G 40TIP41AG, TIP42AG 601 1TIP41BG, TIP42BG 80TIP41CG, TIP42CG 100 BASE BASECollector-Base Voltage VCB Vdc3 3TIP41G, TIP42G 40TIP41AG, TIP42AG 60 EMITTER EMITTERTIP41BG, TIP42BG 80TIP41CG, TIP42CG 1004Emitter-Base Voltage VEB 5.0 VdcTO-220Collector Current - Continuous IC 6.0 AdcCASE 221ACollector Current - Peak ICM 10 Adc
