View tip42 datasheet:

TIP42PNP / Descriptions TO-220 PNP Silicon PNP transistor in a TO-220 Plastic Package. / Features PIN1Base TIP41 PIN 2Collector 1 2 Complement to TIP41. 3 PIN 3Emitter / Applications Medium power linear switching applications. / Absolute Maximum Ratings(Ta=25) Parameter Rating Symbol Unit TIP42 TIP42A TIP42B TIP42C Collector to Base Voltage VCBO -40 -60 -80 -100 VCollector to Emitter Voltage VCEO -40 -60 -80 -100 VEmitter to Base Voltage VEBO -5.0 VCollector Current - Continuous IC -6.0 APeak Collector Current ICP -10 ABase Current - Continuous IB -2.0 ACollector Power Dissipation PC 2.0 WCollector Power Dissipation PC(Tc=25) 65 WTj Junc
