View tip42 datasheet:

TIP42 SERIES(TIP42/42A/42B/42C) PNP EPITAXIAL SILICON TRANSISTORMEDIUM POWER LINEARTO-220SWITCHING APPLICATIONS Complement to TIP41/41A/41B/41CABSOLUTE MAXIMUM RATINGSCharacteristic Symbol Rating Unit Collector Emitter Voltage : TIP42 VCBO -40 V: TIP42A -60 V: TIP42B -80 V: TIP42C -100 V Collector Emitter Voltage : TIP42 VCEO -40 V: TIP42A -60 V: TIP42B -80 V1.Base 2.Collector 3.Emitter: TIP42C -100 V Emitter-Base Voltage VEBO -5 V Collector Current (DC) IC -6 A Collector Current (Pulse) IC -10 A Base Current IB -2 A Collector Dissipation ( TC=25 ) PC 65 W Collector Dissipation ( TA=25 ) PC 2 W Junction Temperature TJ 150 Storage Temperature TSTG -65 ~ 150 ELECTRICAL CHARACTERISTICS (TC =25 )Characteristic Symbol Test Conditions Min Max Unit*Collector Emitter Sustaining Voltage : TIP42 BVCEO(sus) IC = -30mA, IB = 0 -40 V: TIP
