View tip42 tip42a tip42b tip42c datasheet:

tip42_tip42a_tip42b_tip42ctip42_tip42a_tip42b_tip42c

TIP42/A/B/C Rev. H Oct.-2018 DATA SHEET / Descriptions TO-220 PNP Silicon PNP transistor in a TO-220 Plastic Package. / Features TIP41 Complement to TIP41. / Applications Medium power linear switching applications. / Equivalent Circuit / Pinning 1 2 3 PIN1Base PIN 2Collector PIN 3Emitter / hFE Classifications & Marking See Marking Instructions. http://www.fsbrec.com 1 / 6 TIP42/A/B/C Rev. H Oct.-2018 DATA SHEET / Absolute Maximum Ratings(Ta=25) Parameter Rating Symbol Unit TIP42 TIP42A TIP42B TIP42C Collector to Base Voltage VCBO -40 -60 -80 -100 VCollector to Emitter Voltage VCEO -40 -60 -80 -100
