View tip42 tip42a tip42b tip42c datasheet:

SPTECH Product SpecificationSPTECH Silicon PNP Power Transistors TIP42/42A/42B/42CDESCRIPTIONDC Current Gain -h = 30(Min)@ I = -0.3AFE CCollector-Emitter Sustaining Voltage-: V = -40V(Min)- TIP42; -60V(Min)- TIP42ACEO(SUS)-80V(Min)- TIP42B; -100V(Min)- TIP42CComplement to Type TIP41/41A/41B/41CAPPLICATIONSDesigned for use in general purpose amplifer andswitching applicationsABSOLUTE MAXIMUM RATINGS(T =25)aSYMBOL PARAMETER VALUE UNITTIP42 -40TIP42A -60V Collector-Base Voltage VCBOTIP42B -80TIP42C -100TIP42 -40TIP42A -60V Collector-Emitter Voltage VCEOTIP42B -80TIP42C -100V Emitter-Base Voltage -5 VEBOI Collector Current-Continuous -6 ACI Collector Current-Peak -10 ACMBase Current -2 AIBCollector Power Dissipation65T =25CP WCCollector Power Dissipation2T =25aT Junction Temperat
