View tip42 tip42a tip42b tip42c datasheet:

December 2009TIP42/TIP42A/TIP42B/TIP42CPNP Epitaxial Silicon TransistorFeatures Medium Power Linear Switching Applications Complement to TIP41/TIP41A/TIP41B/TIP41CTO-22011.Base 2.Collector 3.EmitterAbsolute Maximum Ratings TA=25C unless otherwise notedSymbol Parameter Value Units VCBO Collector-Base Voltage : TIP42 - 40 V : TIP42A - 60 V : TIP42B - 80 V : TIP42C - 100 V VCEO Collector-Emitter Voltage : TIP42 - 40 V : TIP42A - 60 V : TIP42B - 80 V : TIP42C - 100 V VEBO Emitter-Base Voltage - 5 V IC Collector Current (DC) - 6 A ICP Collector Current (Pulse) -10 A IB Base Current -2 A PC Collector Dissipation (TC=25C) 65 W Collector Dissipation (TA=25C) 2 W TJ Junction Temperature 150 C TSTG Storage Temperature - 65 to 150 C 2009 Fairchild Semiconductor Corporation www.fairchildsemi.comTIP42/TIP42A/TIP42B/TIP42C Re
