View tip42 tip42a tip42b tip42c datasheet:

JIANGSU CHANGJIANG ELECTRONICS TECHNOLOGY CO., LTD TO-220-3L Plastic-Encapsulate Transistors TO-220-3L TIP42/42A/42B/42C TRANSISTOR (PNP) 1. BASE FEATURES 2. COLLECTOR Medium Power Linear Switching Applications Complement to TIP41/41A/41B/41C3. EMITTER MAXIMUM RATINGS (Ta=25 unless otherwise noted) Symbol Parameter TIP42 TIP42A TIP42B TIP42C Unit VCBO Collector-Base Voltage -40 -60 -80 -100 V VCEO Collector-Emitter Voltage -40 -60 -80 -100 V VEBO Emitter-Base Voltage -5 V IC Collector Current -Continuous -6 A PC Collector Power Dissipation 2 W TJ Junction Temperature 150 Tstg Storage Temperature Range -55to+150 ELECTRICAL CHARACTERISTICS (Ta=25 unless otherwise specified) Parameter Symbol Test conditions Min Max UnitCollector-base breakdown voltage TIP42 -40 TIP42A -60 V(BR)CBO IC= -1mA, IE=0 VTIP42B -80 TIP42C
