View tip42 tip42a tip42b tip42c to-220 datasheet:
MCCMicro Commercial ComponentsTMTIP42/42A/42B/42C20736 Marilla Street ChatsworthMicro Commercial ComponentsCA 91311Phone: (818) 701-4933Fax: (818) 701-4939Features Lead Free Finish/RoHS Compliant(Note 1) ("P" Suffix designates RoHS Compliant. See ordering information) Silicon PNP The complementary NPN types are the TIP41 respectively Epoxy meets UL 94 V-0 flammability ratingPower Transistors Moisure Sensitivity Level 1 Marking : Part NumberAbsolute Maximum Ratings @ Ta = 25 (unless otherwise noted) TO-220Symbol Parameter Value UnitB C VCBO -40 TIP42 Collector-base voltage -60 V S F TIP42A (Open emitter) -80 TIP42B -100 TIP42C Q VCEO -40 T TIP42 Collector-emitter voltage -60 V TIP42A (Open base) -80 A TIP42B -100 TIP42C U VEBO Emitter-base Voltage (Open collector) -5 V 1 2
