View tip42 tip42c tip42ctu datasheet:

November 2014TIP42 / TIP42CPNP Epitaxial Silicon TransistorFeatures Medium Power Linear Switching Applications Complement to TIP41 SeriesTO-22011.Base 2.Collector 3.EmitterOrdering InformationPart Number Top Mark Package Packing MethodTIP42 TIP42 TO-220 3L (Single Gauge) BulkTIP42C TIP42C TO-220 3L (Single Gauge) BulkTIP42CTU TIP42C TO-220 3L (Single Gauge) RailAbsolute Maximum RatingsStresses exceeding the absolute maximum ratings may damage the device. The device may not function or be opera-ble above the recommended operating conditions and stressing the parts to these levels is not recommended. In addi-tion, extended exposure to stresses above the recommended operating conditions may affect device reliability. Theabsolute maximum ratings are stress ratings only. Values are at TC = 25C unless otherwise noted.Symbol Parameter Value Unit
