View tip42abc datasheet:

TIP42 SERIES(TIP42/42A/42B/42C)Medium Power Linear Switching Applications Complement to TIP41/41A/41B/41CTO-22011.Base 2.Collector 3.EmitterPNP Epitaxial Silicon TransistorAbsolute Maximum Ratings TC=25C unless otherwise notedSymbol Parameter Value Units VCBO Collector-Base Voltage : TIP42 - 40 V : TIP42A - 60 V : TIP42B - 80 V : TIP42C - 100 V VCEO Collector-Emitter Voltage : TIP42 - 40 V : TIP42A - 60 V : TIP42B - 80 V : TIP42C - 100 V VEBO Emitter-Base Voltage - 5 V IC Collector Current (DC) - 6 A ICP Collector Current (Pulse) -10 A IB Base Current -2 A PC Collector Dissipation (TC=25C) 65 W PC Collector Dissipation (Ta=25C) 2 W TJ Junction Temperature 150 C TSTG Storage Temperature - 65 ~ 150 CElectrical Characteristics TC=25C unless otherwise notedSymbol Parameter Test Condition Min. Max. Units VCEO(sus) * Colle
