View tis73 datasheet:

tis73tis73

TIS73TIS74G TO-92SDN-Channel General Purpose AmplifierThis device is designed for low level analog switching, sampleand hold circuits and chopper stabalized amplifiers. Sourced fromProcess 54.Absolute Maximum Ratings* TA = 25C unless otherwise notedSymbol Parameter Value UnitsVDG Drain-Gate Voltage 30 VV Gate-Source Voltage - 30 VGSIGF Forward Gate Current 10 mATJ, Tstg Operating and Storage Junction Temperature Range -55 to +150 C*These ratings are limiting values above which the serviceability of any semiconductor device may be impaired.NOTES:1) These ratings are based on a maximum junction temperature of 150 degrees C.2) These are steady state limits. The factory should be consulted on applications involving pulsed or low duty cycle operations.Thermal Characteristics TA = 25C unless otherwise notedSymbol Characteristic Max UnitsTIS7
