View tmp10n60 tmpf10n60 datasheet:

TMP10N60/TMPF10N60TMP10N60G/TMPF10N60GVDSS = 660 V @TjmaxFeaturesID = 10A Low gate chargeRDS(on) = 0.75 W(max) @ VGS= 10 V 100% avalanche tested Improved dv/dt capability RoHS compliant Halogen free package JEDEC QualificationDGSDevice Package Marking RemarkTMP10N60 / TMPF10N60 TO-220 / TO-220F TMP10N60 / TMPF10N60 RoHSTMP10N60G / TMPF10N60G TO-220 / TO-220F TMP10N60G / TMPF10N60G Halogen FreeAbsolute Maximum Ratings Parameter Symbol TMP10N60(G) TMPF10N60(G) UnitDrain-Source Voltage VDS 600 VGate-Source Voltage VGS 30 VTC = 25 10 10* AContinuous Drain Current IDTC = 100 6.5 6.5* APulsed Drain Current (Note 1) IDM 40 40* ASingle Pulse Avalanche Energy (Note 2) EAS 758 mJRepetitive Avalanche Current (Note 1) IAR 10 ARepetitive Avalanche Energy (Note 1) EAR 19.8 mJTC = 25 198 52 WPower Dissipati
