agm502.pdf Principales características:

agm502agm502

AGM502 General Description Product Summary The AGM502 combines advanced trench MOSFET to provide technology with a low resistance package extremely low R . DS(ON) device is ideal This for load switch and battery BVDSS RDSON ID protection applications. 60V 2.0 0.3A Features Advance high cell density Trench technology SOT-523 Pin Configuration Low R to minimize conductive loss DS(ON) 3 Low Gate Charge for fast switching Low Thermal resistance ESD 2KV Application MB/VGA Vcore 1 SMPS 2nd Synchronous Rectifier 2 Top View POL application BLDC Motor driver Package Marking and Ordering Information Quantity Device Marking Device Device Package Reel Size Tape width 50A AGM502 SOT-523 3000 178mm 8mm Table 1. Absolute Maximum Ratings (TA=25 ) Symbol Parameter Value Unit VDS Drain-Source Voltage (VGS=0
