2n3772g.pdf datasheet:

2n3772g2n3772g

2N3771, 2N37722N3771 is a Preferred DeviceHigh Power NPN SiliconPower TransistorsThese devices are designed for linear amplifiers, series passregulators, and inductive switching applications.Featureshttp://onsemi.com Forward Biased Second Breakdown Current Capability20 and 30 AMPEREIS/b = 3.75 Adc @ VCE = 40 Vdc - 2N3771 = 2.5 Adc @ VCE = 60 Vdc - 2N3772 POWER TRANSISTORS Pb-Free Packages are Available*NPN SILICON40 and 60 VOLTS, 150 WATTSMAXIMUM RATINGS (Note 1) Rating Symbol 2N3771 2N3772 UnitMARKING Collector-Emitter Voltage VCEO 40 60 VdcDIAGRAM
