2n3773 2n6609.pdf datasheet:
Order this documentMOTOROLAby 2N3773/DSEMICONDUCTOR TECHNICAL DATANPN2N3773*Complementary Silicon PowerPNP2N6609TransistorsThe 2N3773 and 2N6609 are PowerBase power transistors designed for high*Motorola Preferred Devicepower audio, disk head positioners and other linear applications. These devices canalso be used in power switching circuits such as relay or solenoid drivers, dc to dc16 AMPEREconverters or inverters.COMPLEMENTARY High Safe Operating Area (100% Tested) 150 W @ 100 V POWER TRANSISTORS Completely Characterized for Linear Operation 140 VOLTS High DC Current Gain and Low Saturation Voltage 150 WATTShFE = 15 (Min) @ 8 A, 4 VVCE(sat) = 1.4 V (Max) @ IC = 8 A, IB = 0.8 A For Low Distortion Complementary DesignsCASE 107TO204AA
