2n3906 mmbt3906 pzt3906.pdf datasheet:

2n3906_mmbt3906_pzt39062n3906_mmbt3906_pzt3906

2N3906 MMBT3906 PZT3906CCEECC TO-92BBBESOT-223SOT-23Mark: 2APNP General Purpose AmplifierThis device is designed for general purpose amplifier and switchingapplications at collector currents of 10 A to 100 mA.Absolute Maximum Ratings* TA = 25C unless otherwise notedSymbol Parameter Value UnitsVCEO Collector-Emitter Voltage -40 VVCBO Collector-Base Voltage -40 VVEBO Emitter-Base Voltage -5.0 VIC Collector Current - Continuous -200 mAOperating and Storage Junction Temperature Range -55 to +150TJ, Tstg C*These ratings are limiting values above which the serviceability of any semiconductor device may be impaired.NOTES:1) These ratings are based on a maximum junction temperature of 150 degrees C.2) These are steady state limits. The factory should be consulted on applications involving pulsed or low duty cycle operations.Therm
