2n3906 to92.pdf datasheet:

2n3906_to922n3906_to92

SEMICONDUCTOR2N3906TECHNICAL DATA FEATURE TO-92 PNP silicon epitaxial planar transistor for switching and Amplifier applications As complementary type, the NPN transistor 2N3904 is Recommended 1.EMITTER 2.BASE MAXIMUM RATINGS (TA=25 unless otherwise noted) 3. COLLECTOR Symbol Parameter Value Units 1 2 3 VCBO Collector-Base Voltage -40 V VCEO Collector-Emitter Voltage -40 V VEBO Emitter-Base Voltage -5 V IC Collector Current -Continuous -0.2 A PC Collector Power Dissipation 0.625 W TJ Junction Temperature 150 Tstg Storage Temperature -55-150 ELECTRICAL CHARACTERISTICS (Tamb=25 unless otherwise specified) Parameter Symbol Test conditions MIN TYP MAX UNIT Collector-base breakdown voltage V(BR)CBO IC = -10A, IE=0 -40 V Collector-emitter breakdown voltage V(BR)CEO IC =-1mA , IB=0 -40 V Emitter-base breakdown voltage V(
