2n5400.pdf datasheet:

2n54002n5400

2N5400C TO-92BEPNP General Purpose AmplifierThis device is designed for use as general purpose amplifiersand switches requiring high voltages. Absolute Maximum Ratings* TA = 25C unless otherwise notedSymbol Parameter Value UnitsVCEO Collector-Emitter Voltage 120 VVCBO Collector-Base Voltage 130 VVEBO Emitter-Base Voltage 5.0 VICCollector Current - Continuous600mAOperating and Storage Junction Temperature Range -55 to +150TJ, Tstg C*These ratings are limiting values above which the serviceability of any semiconductor device may be impaired.NOTES:1) These ratings are based on a maximum junction temperature of 150 degrees C.2) These are steady state limits. The factory should be consulted on applications involving pulsed or low duty cycle operations.Thermal Characteristics TA = 25C unless otherwise notedSymbol Characteristic Max Units2N5400
