2n5486.pdf datasheet:

2n54862n5486

2N5486JFET VHF/UHF AmplifiersN-Channel DepletionFeatures Pb-Free Packages are Available*http://onsemi.com1 DRAINMAXIMUM RATINGS (TJ = 25C unless otherwise noted)Rating Symbol Value Unit3GATEDrain-Gate Voltage VDG 25 VdcReverse Gate-Source Voltage VGSR 25 Vdc2 SOURCEDrain Current ID 30 mAdcForward Gate Current IG(f) 10 mAdcTotal Device Dissipation @ TC = 25C PD 350 mWDerate above 25C 2.8 mW/COperating and Storage Junction TJ, Tstg -65 to +150 CTemperature RangeStresses exceeding Maximum Ratings may damage the device. MaximumTO-92 (TO-226AA)Ratings are stress ratings only. Functional operation above the RecommendedCASE 29-11Operating Conditions is not implied. Extended exposure to stresses above theSTYLE 5Recommended Operating Conditions may affect device reliability.MARKING DIAGRAM2N5486AYWWGG2N5486 = Devi
