2n7055.pdf datasheet:

2n70552n7055

isc N-Channel MOSFET Transistor 2N7055FEATURESDrain Current: I = 33A@ T =25D CDrain Source Voltage-: V = 200V(Min)DSSStatic Drain-Source On-Resistance: R = 85m(Max)DS(on)Fast SwitchingMinimum Lot-to-Lot variations for robust deviceperformance and reliable operationAPPLICATIONSHigh efficiency switch mode power suppliesActive power factor correctionElectronic lamp ballasts based on half bridge topologyABSOLUTE MAXIMUM RATINGS(T =25)aSYMBOL PARAMETER VALUE UNITV Drain-Source Voltage 200 VDSSV Gate-Source Voltage-Continuous 20 VGSI Drain Current-Continuous 33 ADI Drain Current-Single (pulsed) 132 ADMP Total Dissipation @T =25 180 WD CT Max. Operating Junction Temperature 150 jStorage Temperature -55~150 TstgTHERMAL CHARACTERISTICSSYMBOL PARAMETER MAX UNIT/WR Thermal Re
