2pb709art.pdf datasheet:

2PB709ART45 V, 100 mA PNP general-purpose transistorRev. 01 19 March 2007 Product data sheet1. Product profile1.1 General descriptionPNP general-purpose transistor in a small SOT23 (TO-236AB) Surface-Mounted Device(SMD) plastic package.NPN complement: 2PD601ART.1.2 Features General-purpose transistor Small SMD plastic package1.3 Applications General-purpose switching and amplification1.4 Quick reference dataTable 1. Quick reference dataSymbol Parameter Conditions Min Typ Max UnitVCEO collector-emitter voltage open base - - -45 VIC collector current - - -100 mAhFE DC current gain VCE = -10 V; 210 - 340IC = -2mA2. Pinning informationTable 2. PinningPin Description Simplified outline Symbol1 base3 32 emitter3 collector1122sym0132PB709ARTNXP Semiconductors45 V, 100 mA PNP general-purpose transistor3. Ordering informa
