2PB709ARL; 2PB709ASL45 V, 100 mA PNP general-purpose transistorsRev. 01 12 November 2008 Product data sheet1. Product profile1.1 General descriptionPNP general-purpose transistors in a small SOT23 (TO-236AB) Surface-MountedDevice (SMD) plastic package.Table 1. Product overviewType number[1] Package NPN complementNXP JEDEC2PB709ARL SOT23 TO-236AB 2PD601ARL2PB709ASL 2PD601ASL2PB709ARL/DG SOT23 TO-236AB 2PD601ARL/DG2PB709ASL/DG 2PD601ASL/DG[1] /DG: halogen-free1.2 Features General-purpose transistors Two current gain selections AEC-Q101 qualified Small SMD plastic package1.3 Applications General-purpose switching and amplification1.4 Quick reference dataTable 2. Quick reference dataSymbol Parameter Conditions Min Typ Max UnitVCEO collector-emitter voltage open base - - -45 VIC collector current - - -100 mAhFE DC current gain VCE =
