2pb709brl 2pb709bsl.pdf datasheet:

2PB709BRL; 2PB709BSL50 V, 200 mA PNP general-purpose transistorsRev. 1 28 June 2010 Product data sheet1. Product profile1.1 General descriptionPNP general-purpose transistors in a small SOT23 (TO-236AB) Surface-Mounted Device (SMD) plastic package.Table 1. Product overviewType number Package NPN complementNXP JEDEC2PB709BRL SOT23 TO-236AB 2PD601BRL2PB709BSL 2PD601BSL1.2 Features and benefits Collector current IC -200 mA Two current gain selections AEC-Q101 qualified Small SMD plastic package1.3 Applications General-purpose switching and amplification1.4 Quick reference dataTable 2. Quick reference dataSymbol Parameter Conditions Min Typ Max UnitVCEO collector-emitter voltage open base - - -50 VIC collector current - - -200 mAhFE DC current gain VCE = -10 V; 210 - 460IC = -2mAhFE group R 210 - 340hFE group S 290 - 4602PB7
