2PD602AQL; 2PD602ARL;2PD602ASL50 V, 500 mA NPN general-purpose transistorsRev. 01 27 October 2008 Product data sheet1. Product profile1.1 General descriptionNPN general-purpose transistors in a small SOT23 (TO-236AB) Surface-MountedDevice (SMD) plastic package.Table 1. Product overviewType number[1] Package PNP complementNXP JEDEC2PD602AQL SOT23 TO-236AB -2PD602ARL 2PB710ARL2PD602ASL 2PB710ASL2PD602AQL/DG SOT23 TO-236AB -2PD602ARL/DG 2PB710ARL/DG2PD602ASL/DG 2PB710ASL/DG[1] /DG: halogen-free1.2 Features General-purpose transistors Three current gain selections AEC-Q101 qualified Small SMD plastic package1.3 Applications General-purpose switching and amplification1.4 Quick reference dataTable 2. Quick reference dataSymbol Parameter Conditions Min Typ Max UnitVCEO collector-emitter voltage open base - - 50 VIC collector curre
