2sc2383.pdf datasheet:
2SC2383 TOSHIBA Transistor Silicon NPN Epitaxial Type (PCT Process) 2SC2383 Color TV Vertical Deflection Output Applications Unit: mmColor TV Class-B Sound Output Applications High breakdown voltage: VCEO = 160 V Large continuous collector current capability Recommended for vertical deflection output & sound output applications for line-operated TVs. Complementary to 2SA1013 Absolute Maximum Ratings (Ta = 25C) Characteristics Symbol Rating UnitCollector-base voltage VCBO 160 VCollector-emitter voltage VCEO 160 VEmitter-base voltage VEBO 6 VCollector current IC 1 AJEDEC TO-92MODBase current IB 0.5 AJEITA Collector power dissipation PC 900 mWTOSHIBA 2-5J1AJunction temperature Tj 150 CWeight: 0.36 g (typ.) Storage temperature range Tstg -55 to 150 C Note1: Using continuously under heavy loads (e.g. the applicati
