2sc5603.pdf datasheet:
DATA SHEETNPN SILICON RF TRANSISTOR2SC5603NPN SILICON RF TRANSISTORFLAT-LEAD 3-PIN THIN-TYPE ULTRA SUPER MINIMOLDFEATURES High-gain transistor for buffer amplifier : S21e2 = 10.0 dB TYP. @ VCE = 1 V, IC = 5 mA, f = 2 GHz fT = 25 GHz UHS0 (Ultra High Speed Process) technology adopted Flat-lead 3-pin thin-type ultra super minimold packageORDERING INFORMATIONPart Number Quantity Supplying Form2SC5603 50 pcs (Non reel) 8 mm wide embossed taping2SC5603-T1 3 kpcs/reel Pin 3 (collector) face the perforation side of the tapeRemark To order evaluation samples, consult your NEC sales representative.Unit sample quantity is 50 pcs.ABSOLUTE MAXIMUM RATINGS (TA = +25C)Parameter Symbol Ratings UnitCollector to Base Voltage VCBO 15 VCollector to Emitter Voltage VCEO 6VEmitter to Base Voltage VEBO 2VCollector Current IC
