2sc6144.pdf datasheet:

2sc61442sc6144

Ordering number : ENA1149 2SC6144SANYO SemiconductorsDATA SHEETNPN Epitaxial Planar Silicon Transistor2SC6144High-Current Switching ApplicationsApplications Relay drivers, lamp drivers, motor drivers.Features Adoption of MBIT process. High current capacitance. Low collector-to-emitter saturation voltage. High-speed switching.SpecificationsAbsolute Maximum Ratings at Ta=25CParameter Symbol Conditions Ratings UnitCollector-to-Base Voltage VCBO 60 VCollector-to-Emitter Voltage VCEO 50 VEmitter-to-Base Voltage VEBO 5 VCollector Current IC 10 ACollector Current (Pulse) ICP 13 ABase Current IB 2 A2 WCollector Dissipation PCTc=25C25 WJunction Temperature Tj 150 CStorage Temperature Tstg --55 to +150 CAny and all SANYO Semiconductor Co.,Ltd. products described or contained herein are, with regard to "standard appli
