3cg1132.pdf datasheet:

2SB1132(3CG1132) PNP /SILICON PNP TRANSISTOR Purpose: Medium power amplifier applications. , 2SD1664(3DG1664) Features: Low saturation voltage, complements the 2SD1664(3DG1664). /Absolute maximum ratings(Ta=25) Symbol Rating Unit VCBO -40 V VCEO -32 V VEBO -5.0 V IC -1.0 A ICP -2.0 A PC 500 mW P (Tc=25)C 2.0 W Tj 150 Tstg -55150 /Electrical characteristics(Ta=25) Rating Symbol Test condition Unit Min Typ Max V I =-50A I =0 -40 V CBO C BV I =-1.0mA I =0 -32 V CEO C BV I =-50A I =0 -5.0 V EBO E CI V =-20V I =0 -0.5 A CBO CB EI V =-4.0V I =0 -0.5 A
