apt20gf120brd.pdf datasheet:
APT20GF120BRD1200V 32AFast IGBT & FREDThe Fast IGBT is a new generation of high voltage power IGBTs. Using Non- TO-247Punch Through Technology the Fast IGBT combined with an APT free-wheeling ultraFast Recovery Epitaxial Diode (FRED) offers superiorruggedness and fast switching speed.G Low Forward Voltage Drop High Freq. Switching to 20KHzCCE Low Tail Current Ultra Low Leakage Current RBSOA and SCSOA RatedG Ultrafast Soft Recovery Antiparallel DiodeEMAXIMUM RATINGS (IGBT) All Ratings: TC = 25C unless otherwise specified.Symbol Parameter APT20GF120BRD UNITVCES Collector-Emitter Voltage 1200VCGR Collector-Gate Voltage (RGE = 20K) 1200VoltsVGE Gate-Emitter Voltage 20IC1 Continuous Collector Current @ TC = 25C 32IC2 Continuous Collector Current @ TC = 90C 20Amps1ICM1 Pulsed Collector Current @ TC =
