apt20gt60br.pdf datasheet:
APT20GT60BRAPT20GT60BR600V 40AThunderbolt IGBTTO-247The Thunderbolt IGBT is a new generation of high voltage power IGBTs.Using Non-Punch Through Technology the Thunderbolt IGBT offers superiorruggedness and ultrafast switching speed.C Low Forward Voltage Drop High Freq. Switching to 150KHzGCE Low Tail Current Ultra Low Leakage CurrentG Avalanche Rated RBSOA and SCSOA RatedEMAXIMUM RATINGS All Ratings: TC = 25C unless otherwise specified.SymbolParameter UNITAPT20GT60BRVCES Collector-Emitter Voltage600VCGR Collector-Gate Voltage (RGE = 20KW)600VoltsVEC Emitter-Collector Voltage15VGE Gate-Emitter Voltage20IC1 Continuous Collector Current @ TC = 25C40IC2 Continuous Collector Current @ TC = 90C20AmpsICM Pulsed Collector Current 1 @ TC = 25C80ILM RBSOA Clamped Inductive Load Cur
