apt94n60l2c3.pdf datasheet:

APT94N60L2C3600V 94A 0.035Super Junction MOSFETTO-264MaxCOOLMOSPower Semiconductors Ultra low RDS(ON) Low Miller CapacitanceD Ultra Low Gate Charge, QgG Avalanche Energy Rated TO-264 Max PackageSMAXIMUM RATINGS All Ratings: TC = 25C unless otherwise specified.Symbol Parameter APT94N60L2C3 UNITVDSS Drain-Source Voltage600 VoltsID Continuous Drain Current @ TC = 25C94AmpsIDM Pulsed Drain Current 1282VGS Gate-Source Voltage Continuous20VoltsVGSM Gate-Source Voltage Transient30Total Power Dissipation @ TC = 25C833 WattsPDLinear Derating Factor6.67 W/CTJ,TSTG Operating and Storage Junction Temperature Range-55 to 150CTL Lead Temperature: 0.063" from Case for 10 Sec.300dv/dt Drain-Source Voltage slope (VDS = 480V, ID = 94A, TJ = 125C)50 V/nsIAR Repetitive
