bd135 bd137 bd139.pdf datasheet:
BD135/137/139NPN Epitaxial Planar Transistors1. EMITTER2. COLLECTORP b Lead(Pb)-Free3. BASE123TO-126ABSOLUTE MAXIMUM RATINGS(TA=25C)Rating Symbol BD135 BD137 BD139 UnitVCBO45 60 80 VCollector-Emitter VoltageVCEO45 60 80 VCollector-Base VoltageVEBOEmitter-Base Voltage 5.0 5.0 5.0 VCollector Current IC1.5 APD1.25 WPower DisspationTj150 CJunction TemperatureTstgStorage , Temperature -55 to +150 C Classification Of hFE(2)Rank 6 10 16Range 40-100 63-160 100-250Device MarkingBD135 = BD135 , BD137 = BD137 , BD139 = BD139WEITRON1/3 07-Apr-10http://www.weitron.com.twBD135/137/139ELECTRICAL CHARACTERISTICS (TA=25C unless otherwise noted) (Countinued)Characteristics Symbol Min Max UnitCollector-Emitter Breakdown VoltageIC = 100A, IE = 0BD135 45V-V(BR)CBOBD137 60BD139 80Collector-Base Brea
