bd136 bd138 bd140.pdf datasheet:

bd136_bd138_bd140bd136_bd138_bd140

BD136BD138/BD140PNP SILICON TRANSISTORS SGS-THOMSON PREFERRED SALESTYPES PNP TRANSISTORDESCRIPTIONThe BD136, BD138 and BD140 are siliconepitaxial planar PNP transistors in Jedec SOT-32plastic package, designed for audio amplifiersand drivers utilizing complementary or quasicompementary circuits.12The complementary NPN types are the BD1353BD137 and BD139.SOT-32INTERNAL SCHEMATIC DIAGRAMABSOLUTE MAXIMUM RATINGSSymbol Parameter Value UnitBD136 BD138 BD140VCBO Collector-Base Voltage (IE = 0) -45 -60 -80 VV Collector-Emitter Voltage (I = 0) -45 -60 -80 VCEO BVEBO Emitter-Base Voltage (IC = 0) -5 VI Collector Current -1.5 ACI Collector Peak Current -3 ACMIB Base Current -0.5 AoP Total Dissipation at T 25 C12.5 Wtot coPtot Total Dissipation at Tamb 25 C1.25 WoTstg Storage Temperature -65 to 150 CoT Max. Opera
