bf1107 2.pdf datasheet:

BF1107N-channel single gate MOSFETRev. 04 9 January 2007 Product data sheet1. Product profile1.1 General descriptionThe BF1107 is a depletion type field-effect transistor in a SOT23 package. The low lossand high isolation capabilities of this MOSFET provide excellent RF switching functions.Integrated diodes between gate and source and between gate and drain protect againstexcessive input voltage surges. Drain and source are interchangeable.CAUTIONThis device is sensitive to ElectroStatic Discharge (ESD). Therefore care should be takenduring transport and handling.1.2 Features Currentless RF switch1.3 Applications Various RF switching applications such as: Passive loop through for VCR tuner Transceiver switching1.4 Quick reference dataTable 1. Quick reference dataSymbol Parameter Conditions Min Typ Max UnitLins(on) on-state insertion loss V
