ci15t60.pdf datasheet:

CI15T6015A600V Field Stop Trench IGBT Features Outline Positive temperature Co-efficient for easy parallel operation. TO-220AB Short collector time-5us. High current capability.0.420(10.66)0.197(5.0)MAX High input impedance.0.386(9.80)0.055(1.40) Low saturation voltage : VCE(sat) = 1.65@25OC.0.043(1.10) Fast switching : 20KHz ~ 40KHz(Ta = 25OC).0.226(5.75)MIN Suffix "G" indicates Halogen-free part, ex.CI15T60G.0.624(15.87)MAX0.155(3.94)Marking codeMAXG C E Mechanical dataC0.054(1.37) 0.115(2.92)MAX 0.081(2.05) Epoxy : UL94-V0 rated flame retardant.0.038(0.96)0.500(12.70)MIN Case : JEDEC TO-220AB molded plastic body. 0.250(6.35)0.020(0.50)MING Terminals : Solder plated, solderable perMIL-STD-750, Method 2026.E Polarity: As marked.0.110(2.80) 0.028(0.70)0.091(2.30) 0.011(
