cmut2222a.pdf datasheet:

cmut2222acmut2222a

CMUT2222Awww.centralsemi.comSURFACE MOUNTDESCRIPTION:NPN SILICON TRANSISTORThe CENTRAL SEMICONDUCTOR CMUT2222A type is an NPN silicon transistor manufactured by the epitaxial planar process, epoxy molded in an ULTRAmini surface mount package, designed for small signal general purpose and switching applications. MARKING CODE: PC1SOT-523 CASEMAXIMUM RATINGS: (TA=25C) SYMBOL UNITSCollector-Base Voltage VCBO 75 VCollector-Emitter Voltage VCEO 40 VEmitter-Base Voltage VEBO 6.0 VContinuous Collector Current IC 600 mAPower Dissipation PD 250 mWOperating and Storage Junction Temperature TJ, Tstg -65 to +150 CThermal Resistance JA 500 C/WELECTRICAL CHARACTERISTICS: (TA=25C unless otherwise noted)SYMBOL TEST CONDITIONS MIN MAX UNITSICBO VCB=60V 10 nAICBO VCB=60V, TA=125C 10 AICEV VCE=60V, VEB=3.0V 10 nAIEBO VEB=3.0V 10 nABVC
